FSP1510BL series

Products used in: communication equipment, network terminals, storage equipment, LED lamps, consumer electronics, power supply devices

Security equipment, etc.

Description: The FSP-25 series thermally conductive silicone sheets are made of silicone rubber as the matrix and filled with thermally conductive ceramic powder. They have good thermal conductivity and insulation. Features: Contains no harmful substances, insulation, excellent flame retardant performance, high and low temperature resistance, high compression performance Low oil output Excellent thermal conductivity, can be used to fill structural gaps Specification: 200mm*400mm Roll material Applications: Chips Routers Computers Mobile LEDs

Key words:

Classification:

Telephone:

Description:

The FSP-25 series thermally conductive silicone sheets are made with silicone rubber as the base material and filled with thermally conductive ceramic powder. They possess good thermal conductivity and insulation properties.
Features:

◆Contains no harmful substances, insulation, excellent flame retardant properties, high and low temperature resistance, high compression performance
◆Low oil bleed
◆Excellent thermal conductivity, suitable for filling structural gaps
Specification:
▲200mm*400mm
▲Roll material
Applications：
●Chips
●Routers
●Computers
●Mobile phones
●Light emitting diodes

Project	Unit	FSP-3040	FSP-3060	Test Standard
Color	/	Purple	Purple	Visual inspection
Density	g/cm³	2.6	2.6	ASTM D792
Thermal Conductivity	W/m.k	2.5	2.5	ASTM D5470
Dielectric Strength	KV/mm	>6	>6	ASTM D149
Thickness (±10%)	mm	0.3~15.0	0.3~15.0	ASTM D374
Hardness	Shore OO	40	60	ASTM D2240
Flammability Rating	/	UL94-V0	UL94-V0	UL 94
Operating Temperature	℃	-40~+200	-40~+200	— —
Self-Adhesiveness	/	Double-sided adhesive	Double-sided micro-adhesive	— —
Adhesive Selection	/	√	√	— —
Fiberglass Reinforced	/	√	√	— —

Customizable according to Your Requests
